FLOW RATE TO 581 LPM(153.5 GPM)(34.86 M³/Hr.)(Pressure Ratio – 1 : 1)
AIR SUPPLY PRESSURE = 2 BAR (29.01 PSIG) to 8.6 BAR (124.7 PSIG)

  • Port Size – Tri - Clamp Connections

    • Liquid Inlet / Suction Port – 2"

    • Liquid Outlet / Discharge Port  - 2"

    • Air Inlet – ¾" BSP

    • Air Exhaust - 1" Female NPT (Includes Neo-Muff Silencer)





Note:

Pump incorporated with Neo-Tef PTFE

Diaphragms will reduce the Output by 37%

Flow Rate: 361 LPM (95.4 GPM) (21.7 M3/Hr.)



 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

EOM

sf 50 EOM

Flammable Product Transfer Safety Manual



BROCHURE

sf 50 Brochure



FLYERS

Neo-Flo Design

Saniflux Flyer

Neo-Flo Competitive Matrix - pdf



SPARES LIST

sf 50 Spares List







- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

  • Suction Lift

      Rubber Diaphragm                   PTFE Diaphragms

      Dry – 3.2 meter (10.5 ft.)         Dry – 2.4 meter (7.87 ft.)

      Wet – 9.0 meter (29.5 ft.)        Wet – 8.7 meter (28.5 ft.)

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

  • Maximum Particle Size / Maximum Compressible Solids:  Ball Valve  -  ½" (12.7mm) , Flap Valve  - 1-5/8" (41.5 mm)

  • Displacement per Stroke* – 1.09 Liter (0.28 gallon)

  • Ship Weight

    • Stainless Steel 316 ………… 50 kg. (110 lb.)

  • Typical Noise Level - 69dB (with Neo-Muff Silencer)

  • Pump Dimensions – Height 1010mm (40") X Width 472mm (19") X Depth 400mm (16")

* Displacement per stroke was calculated at 4.9 bar (71 psig) air inlet pressure against a 2.2 bar (31 psig) head pressure.
