FLOW RATE TO 135 LPM(35.6 GPM)(8.10 M³ / Hr.)(PressureRatio – 1 : 1)
AIR SUPPLY PRESSURE = 2 BAR(29.01 PSIG) to 8.6 BAR(124.7 PSIG)

  • Port Size –Tri - Clamp Connections

    • Liquid Inlet / Suction Port – 1"

    • Liquid Outlet / Discharge Port  - 1"

    • Air Inlet – ½" BSP

    • Air Exhaust - ½" Female NPT (Includes Neo-Muff Silencer)





Note:

Pump incorporated with Neo-Tef PTFE

Diaphragms will reduce the Output by 19%

Flow Rate: 110 LPM (29.1 GPM) (6.6 M3/Hr.)



 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

EOM

sf 25 EOM

Flammable Product Transfer Safety Manual



BROCHURE

sf 25 Brochure



FLYERS

Neo-Flo Design

Saniflux Flyer

Neo-Flo Competitive Matrix



SPARES LIST

sf 25 Spares List







- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

  • Suction Lift

      Rubber Diaphragm                   PTFE Diaphragms

      Dry - 3.3 meter (10.8 ft.)           Dry – 2.0 meter (6.5 ft.)

      Wet - 8.3 meter (27.2 ft.)         Wet – 8.1 meter (26.5 ft.)



- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

  • Maximum Particle Size / Maximum Compressible Solids:  Ball Valve  -  5.5mm

  • Displacement per Stroke* – 0.3 Liter (0.07 gallon) (Rubber Fitted) , 0.05 Liter (0.02 Gallon) (PTFE Fitted)

  • Ship Weight

    • Stainless Steel 316 ………… 50 kg. (110 lb.)

  • Typical Noise Level - 69dB (with Neo-Muff Silencer)

  • Pump Dimensions – Height 1010mm (40") X Width 472mm (19") X Depth 400mm (16")

* Displacement per stroke was calculated at 4.9 bar (71 psig) air inlet pressure against a 2.2 bar (31 psig) head pressure.
