FLOW RATE TO 210 LPM (55 GPM) (12.6 M³ / Hr.) (Pressure Ratio – 1 : 1)
AIR SUPPLY PRESSURE = 2 BAR (29.01 PSIG) to 8.6 BAR (124.7 PSIG)

  • Port Size – ANSI Flange

    • Liquid Inlet / Suction Side – 1"

    • Liquid Outlet / Discharge Side  - 1"

    • Air Inlet – ½" BSP

    • Air Exhaust - ½" Female NPT (Includes Neo-Muff Silencer).

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

 |

EOM

nfp 25 EOM

Flammable Product Transfer Safety Manual



BROCHURE

nfp 25 Brochure



FLYERS

Neo-Flo Design

Neo-Flo Competitive Matrix



SPARES LIST

nfp 25 Spares List











- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

  • Suction Lift

      Rubber Diaphragm                   PTFE Diaphragm

      Dry - 3.4 meter (11.8 ft.)           Dry – 2.2 meter (7.2 ft.)

      Wet – 9.0 meter (29.5 ft.)         Wet – 8.8 meter (28.8 ft.)

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -



  • Maximum Particle Size / Maximum Solids Passage –  3/16" (5.1mm)

  • Displacement per Stroke* – 0.30 Liter (0.08 gallon)

  • Typical Noise Level - 70dB (with Neo-Muff Silencer)

  • Ship Weight

    • Polypropylene ……………….…… 15 kg. (33 lb.)

  • Pump Dimensions – Height 437mm (17.2") X Width 468mm (18.4") X Depth 257mm (10.1")

* Displacement per stroke was calculated at 4.9 bar (71 psig) air inlet pressure against a 2.2 bar (31 psig) head pressure.

- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Performance Chart - - - - - - - - - - - - - - - - - -

Flow indicates in chart are determined by pumping water. Based on Specific Gravity of 1.0
For optimum life and performance, pumps should be specified so that daily operation parameters will fall in the center of the pump performance curve.
